Eco-friendly Crack Printing Paste 9166 | Distressed Crackle Effect | CLT
CLT 9166 is an eco-friendly crackle paste designed to create artistic distressed effects on textiles. It features easy cracking by hand after curing, delivering distinct crack patterns with excellent wash fastness. Perfect for vintage or street-style designs on cotton and knitted fabrics.
Key Features:
Technical Specifications | 9166 Crack Paste
Technical data and compliance standards for CLT 9166 crack printing paste.
Product Specifications
Printing Guide | 9166 Crack Paste
Step-by-step instructions for creating optimal crackle effects with CLT 9166.
Printing Conditions
| Humidity | 50-80% |
| Temperature | Room temperature |
| Squeegee Type | 55-65 degree water-based squeegee |
| Mesh Count | 100-135 mesh |
| Curing Temperature | 130-140°C |
| Curing Time | 90 seconds |
Printing Process
Prepare formulation (e.g., 70% 9166 + 30% 9166C). Add 1% PC-100 cross-linker for enhanced fastness. Stir thoroughly. Use within 6-8 hours.
Print directly on cotton fabric (2-3 passes, 3 strokes each). No underbase required.
Cure at 130-140°C for 90 seconds. After cooling, pull the fabric by hand to create the crackle effect.
Eco-Friendly Certifications & Test Results
9166 meets international safety and environmental standards.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Standard |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
| AZO Dyes | PASS | OEKO-TEX 100 |
Finished Product Performance
Performance evaluation for 9166 on non-elastic 100% cotton fabric.
Test Conditions
Fabric
Non-elastic 100% Cotton
Printing Method
3 passes, 3 strokes each
Curing Condition
135°C × 90s
Performance Metrics
Softness
Grade 1
5-grade scale (5=very soft, 1=hard)
Elasticity
Grade 1
5-grade scale (5=excellent, 1=poor)
Gloss
Matte (9166) / Flat (9166C)
Visual inspection
Machine Wash Fastness
Pass
60°C wash cycles; wash & dry ×5 (2.5h per cycle)
Dry Rubbing Fastness
Grade 3
GB/T 3920-2008, 10 cycles
Wet Rubbing Fastness
Grade 3
GB/T 3920-2008, 10 cycles
Blocking Resistance
Pass
No adhesion at 80°C under 5kg for 24h
Formulation & Auxiliaries
Recommended formulation and cross-linker for crackle effects.
Recommended Formulation (Shade-Based)
| Component | Light | Medium | Dark |
|---|---|---|---|
| 9166 (White) | 70% | 45-55% | 5-15% |
| 9166C (Clear) | 30% | 45-55% | 85-95% |
| Pigment | 3-5% | 6-8% | 8-12% |
Auxiliary Agents
Cross-linker (PC-100)
Usage
1%
Purpose
Essential for high wash fastness and crack durability
Notes
Mix thoroughly and use within 6-8 hours.
Humectant (MDR)
Usage
As needed
Purpose
Prevent mesh clogging when humidity < 50%
Notes
Ensures stable printing in dry conditions.
Storage & Shelf Life
Storage instructions to maintain the cracking performance of 9166.
Storage Conditions
Temperature
5-35°C
Humidity
Cool and ventilated place
Sealing
Keep container tightly sealed
Shelf Life
10 months from manufacturing date
Important Warnings
- ⚠Colorant addition must not exceed 10% to avoid color bleeding.
- ⚠Ensure prints are fully dry before wash testing (typically 24 hours).
- ⚠Keep away from direct sunlight and heat sources.
- ⚠Avoid freezing during storage and transport.
