Eco-friendly Photochromic Printing Paste 232 | UV Sensitive Ink | CLT
CLT 232 is an eco-friendly photochromic paste that displays vibrant colors when exposed to sunlight or UV light. It returns to its original color when the UV source is removed. This product features excellent transparency, high color saturation, and superior wash fastness.
Key Features:
Technical Specifications | 232 Photochromic Paste
Key technical data and compliance information for CLT 232 photochromic printing paste.
Product Specifications
Printing Guide | 232 Photochromic Paste
Recommended printing conditions and process steps for CLT 232 photochromic paste.
Printing Conditions
| Humidity | 50-80% |
| Temperature | Room temperature |
| Squeegee Hardness | 55-65 (oil-based) |
| Mesh Count | 100-135 mesh |
| Curing Temperature | 130-140°C |
| Curing Time | 90 seconds |
Printing Process
Add 0.5% PC-100 cross-linker to 232 paste. Stir thoroughly. Use within 6-8 hours after mixing.
Check if fabric is sublimation-prone. If so, apply anti-sublimation underbase first. Print 232 paste (suggested 1 pass, 2 strokes).
Cure at 130-140°C for 90 seconds. Perform wash tests only after full drying (typically 24 hours).
Eco-Friendly Certifications & Test Results
CLT 232 meets international safety standards for textile printing.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Adidas A-01 |
| AZO Dyes | PASS | OEKO-TEX 100 |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
Finished Product Performance
Test results for CLT 232 photochromic paste on 100% cotton fabric.
Test Conditions
Fabric
100% Cotton
Printing Method
1 pass, 2 strokes
Curing Condition
135°C × 90s
Performance Metrics
Softness
Grade 5
5-grade scale (5=very soft, 1=hard)
Machine Wash Fastness
Pass
40°C wash cycles; wash & dry ×5
Dry Rubbing Fastness
Grade 5
GB/T 3920-2008, 10 cycles
Wet Rubbing Fastness
Grade 5
GB/T 3920-2008, 10 cycles
Blocking Resistance
Pass
No adhesion at 80°C under 5kg for 24h
Freeze Resistance
Pass
Stable at -20°C for 24 hours
Formulation & Auxiliaries
Recommended formulation and cross-linking agent for CLT 232.
Auxiliary Agents
Cross-linker (PC-100)
Usage
0.5%
Purpose
Enhance wash and rubbing fastness
Notes
Mix thoroughly and use within 6-8 hours.
Humectant (MDR)
Usage
As needed
Purpose
Prevent screen clogging when humidity < 50%
Notes
Add in dry environments.
Storage & Shelf Life
Critical storage guidelines to maintain photochromic activity of CLT 232.
Storage Conditions
Temperature
5-35°C
Humidity
Cool and ventilated place
Sealing
Keep container tightly sealed
Shelf Life
6 months from manufacturing date
Important Warnings
- ⚠STORE IN A DARK PLACE. Avoid direct exposure to sunlight and UV sources during storage.
- ⚠Keep container well-sealed to prevent surface skinning.
- ⚠Stir thoroughly before each use.
- ⚠Avoid freezing during transport and storage.
