Eco-friendly Sand Surface Printing Paste MP2500-3 | Matte Sand Effect | CLT
CLT MP2500-3 is an eco-friendly sand surface paste engineered to provide a sophisticated matte sand texture to fabrics. It features high fastness, exceptional elasticity, and ease of operation, making it ideal for high-volume machine printing on oval or octopus-style printing machines.
Key Features:
Technical Specifications | MP2500-3 Sand Surface Paste
Comprehensive technical data for CLT MP2500-3 sand surface printing paste.
Product Specifications
Printing Guide | MP2500-3 Sand Surface Paste
Operational parameters and printing process for CLT MP2500-3.
Printing Conditions
| Humidity | 50-70% |
| Temperature | Room temperature |
| Squeegee Hardness | 75 degree (oil-based) |
| Mesh Count | 80 mesh |
| Flash Cure (Machine) | 65-70°C for 5-7 seconds |
| Curing Temperature | 130-140°C |
| Curing Time | 90 seconds |
| Heat Press (Optional) | 135°C × 10 seconds |
Printing Process
Prepare formulation with MP2500-3 and MP2500C-3. Add 1% PC-100 cross-linker and stir thoroughly. Use within 6-8 hours.
Apply underbase if needed (e.g., 982-4 for Modal). Machine print 3 passes (3 strokes each) with 80 mesh screen.
Cure at 130-140°C for 90 seconds. Full fastness achieved after 24 hours of drying.
Eco-Friendly Certifications & Test Results
MP2500-3 meets strict environmental and safety requirements.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Standard |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
| AZO Dyes | PASS | OEKO-TEX 100 |
Finished Product Performance
Performance evaluation for MP2500-3 on 100% cotton fabric.
Test Conditions
Fabric
100% Cotton
Printing Method
Machine printing (3 passes, 3 strokes each)
Curing Condition
135°C × 90s
Performance Metrics
Softness
Grade 4
5-grade scale (5=very soft, 1=hard)
Elasticity
Grade 5
5-grade scale (5=excellent, 1=poor)
Gloss
Matte (Flat)
Visual inspection
Machine Wash Fastness
Pass
60°C wash cycles; wash & dry ×5 (2.5h per cycle)
Dry Rubbing Fastness
Grade 4
GB/T 3920-2008, 10 cycles
Wet Rubbing Fastness
Grade 4
GB/T 3920-2008, 10 cycles
Blocking Resistance
Pass
No adhesion at 80°C under 5kg for 24h
Formulation & Auxiliaries
Recommended mixing ratios and auxiliary agents for sand surface effects.
Recommended Formulation (Shade-Based)
| Component | Light | Medium | Dark |
|---|---|---|---|
| MP2500-3 (White) | 70% | 45-55% | 5-15% |
| MP2500C-3 (Clear) | 30% | 45-55% | 85-95% |
| Pigment | 3-5% | 6-7% | 8-12% |
Auxiliary Agents
Cross-linker (PC-100)
Usage
1%
Purpose
Essential for high wash fastness
Notes
Mix thoroughly and use within 6-8 hours.
Underbase Paste (982-4 / 985)
Usage
As required
Purpose
Improve adhesion on Modal, Lycra, or Mercerized cotton
Notes
Use with 1% PC-500 for Modal/Odel fabrics.
Humectant (MDR)
Usage
As needed
Purpose
Prevent mesh clogging when humidity < 50%
Notes
Ensures stable continuous machine printing.
Storage & Shelf Life
Storage instructions to maintain the quality of MP2500-3 sand surface paste.
Storage Conditions
Temperature
5-35°C
Humidity
Cool and ventilated place
Sealing
Keep container tightly sealed
Shelf Life
10 months from manufacturing date
Important Warnings
- ⚠Low temperature cross-linking product: Flash cure at 65-70°C for 5-7s on machine.
- ⚠Keep away from direct sunlight and heat sources.
- ⚠Avoid freezing during storage and transport.
- ⚠Stir thoroughly before use to ensure uniform sand distribution.
