Eco-friendly Water-based Paste S627 | Soft Feel Fabric Ink | CLT
CLT S627 is a high-performance eco-friendly water-based paste characterized by its excellent fastness, exceptionally soft hand feel, and superior dry/wet rubbing fastness. It delivers vibrant color results and prevents whitening after washing. Suitable for manual, flat screen, and rotary screen printing.
Key Features:
Technical Specifications | S627 Water-based Paste
Key technical data and eco-compliance information for CLT S627 water-based paste.
Product Specifications
Printing Guide | S627 Water-based Paste
Optimal printing conditions and process steps for CLT S627 water-based paste.
Printing Conditions
| Humidity | 50-80% (optimal) |
| Temperature | Pay attention to temperature effects on operation |
| Squeegee Hardness | 55-65 (oil-based) |
| Mesh Count | 100-135 mesh |
| Curing Temperature | 130-140°C |
| Curing Time | 90 seconds |
Printing Process
Mix S627 with pigment (1-10% depending on shade). If extra fastness is needed, add 1% PC-500 cross-linker and stir thoroughly.
Print the mixture. Adjust humidity: use MDR humectant if <50% to prevent clogging; extend curing if >80% to avoid tackiness.
Cure at 130-140°C for 90 seconds. Full fastness is achieved after complete drying.
Eco-Friendly Certifications & Test Results
CLT S627 compliance with international textile safety standards.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Adidas A-01 |
| AZO Dyes | PASS | OEKO-TEX 100 |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
Finished Product Performance
Test results for CLT S627 water-based paste on 100% cotton fabric.
Test Conditions
Fabric
100% Cotton
Printing Method
1 pass, 1 stroke (machine printing)
Curing Condition
135°C × 90s
Performance Metrics
Softness
Grade 4
5-grade scale (5=very soft, 1=hard)
Elasticity
Grade 1
5-grade scale (5=excellent, 1=poor)
Machine Wash Fastness
Pass
60°C wash cycles; wash & dry ×5
Dry Rubbing Fastness
Grade 5
GB/T 3920-2008, 10 cycles
Wet Rubbing Fastness
Grade 5
GB/T 3920-2008, 10 cycles
Odor Test
None
Formulation & Auxiliaries
Recommended formulation and cross-linking agents for CLT S627.
Reference Formulation (Shade-Based)
| Component |
|---|
Auxiliary Agents
Cross-linker (PC-500)
Usage
1%
Purpose
Enhance wash fastness
Notes
Stir thoroughly and use within 24 hours after mixing.
Humectant (MDR)
Usage
As needed
Purpose
Prevent screen clogging when humidity < 50%
Notes
Add in dry environments.
Storage & Shelf Life
Storage guidelines for maintaining the stability of CLT S627 water-based paste.
Storage Conditions
Temperature
5-35°C
Humidity
Cool and ventilated place
Sealing
Keep container tightly sealed
Shelf Life
10 months from manufacturing date
Important Warnings
- ⚠Use within 24 hours after adding cross-linker.
- ⚠Adjust curing time based on environmental humidity.
- ⚠Avoid using non-CLT auxiliaries without prior compatibility testing.
- ⚠Stir thoroughly before use.
