Eco-friendly Water-based Thick Plate Printing Paste 811-2 | High Build Ink | CLT
CLT 811-2 is a premium water-based thick plate paste designed for high-end 3D screen printing effects. It features excellent height building properties, remains stable without sagging or edge curling, and delivers a soft hand feel with high elasticity. Ideal for both manual and machine printing on various textiles.
Key Features:
Technical Specifications | 811-2 Thick Plate Paste
Technical data and compliance standards for CLT 811-2 thick plate printing paste.
Product Specifications
Printing Guide | 811-2 Thick Plate Paste
Recommended printing conditions and process for achieving optimal height with 811-2.
Printing Conditions
| Humidity | 50-80% |
| Temperature | Room temperature |
| Squeegee Hardness | 55-65 degree (oil-based) |
| Mesh Count | 80-120 mesh |
| Curing Temperature | 130-140°C |
| Curing Time | 90 seconds |
| Heat Press (Optional) | 135°C × 10 seconds |
Printing Process
Prepare formulation with 811-2 and 811C-2. Add 1% PC-100 cross-linker and stir thoroughly. Use within 8-12 hours.
Apply underbase if needed (e.g., 982 for Modal). Print 10 passes (3 strokes each) to build desired height.
Cure at 130-140°C for 90 seconds. For high rubbing fastness (Grade 4+), apply M1204 top coat. Allow prints to fully dry for 24 hours.
Eco-Friendly Certifications & Test Results
811-2 meets stringent international safety and environmental standards.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | PASS | Standard |
| APEO | PASS | OEKO-TEX 100 |
| Phthalates | PASS | OEKO-TEX 100 |
| AZO Dyes | PASS | OEKO-TEX 100 |
Finished Product Performance
Performance metrics for 811-2 on 100% cotton fabric.
Test Conditions
Fabric
100% Cotton
Printing Method
10 passes, 3 strokes each
Curing Condition
135°C × 90s
Performance Metrics
Softness
Grade 3
5-grade scale (5=very soft, 1=hard)
Elasticity
Grade 4
5-grade scale (5=excellent, 1=poor)
Gloss
Matte (Flat)
Visual inspection
Machine Wash Fastness
Pass
60°C wash cycles; wash & dry ×5 (2.5h per cycle)
Dry Rubbing Fastness
Grade 3-4
GB/T 3920-2008, 10 cycles
Wet Rubbing Fastness
Grade 3-4
GB/T 3920-2008, 10 cycles
Blocking Resistance
Pass
No adhesion at 80°C under 5kg for 24h
Freeze Resistance
Pass
Stable at -15°C for 24 hours
Formulation & Auxiliaries
Recommended formulation and auxiliary agents for 3D thick plate effects.
Recommended Formulation (Shade-Based)
| Component | Light | Medium | Dark |
|---|---|---|---|
| 811-2 (White) | 70% | 45-55% | 5-15% |
| 811C-2 (Clear) | 30% | 45-55% | 85-95% |
| Pigment | 3-5% | 6-8% | 8-12% |
Auxiliary Agents
Cross-linker (PC-100)
Usage
1%
Purpose
Improve build stability and wash fastness
Notes
Mix thoroughly and use within 6-8 hours to avoid thickening.
Underbase Paste (982 / 985)
Usage
As required
Purpose
Enhance adhesion on specialized fabrics
Notes
Use 982 for Modal/Odel, 985 for Mercerized cotton.
Top Coat Paste (M1204)
Usage
As required
Purpose
Achieve dry/wet rubbing fastness Grade 4+
Notes
Apply as a final layer over thick plate prints.
Humectant (MDR)
Usage
As needed
Purpose
Prevent mesh clogging when humidity < 50%
Notes
Essential for maintaining open mesh during multi-pass printing.
Storage & Shelf Life
Storage instructions to maintain the stability and high-build performance of 811-2.
Storage Conditions
Temperature
5-35°C
Humidity
Cool and ventilated place
Sealing
Keep container tightly sealed
Shelf Life
10 months from manufacturing date
Important Warnings
- ⚠Product must be used with 1% PC-100. Use within 6-8 hours after mixing to prevent clumping.
- ⚠Ensure prints are fully dry before wash testing; cross-linking may be slower in high humidity.
- ⚠Keep away from direct sunlight and heat sources.
- ⚠Avoid freezing during storage and transport.
