MP399 High Foaming Paste | Water-based 3D Printing Supplies | CLT
MP399 is designed for screen printers seeking maximum foaming height without compromising on surface smoothness. Its advanced water-based formula ensures excellent compatibility with common pastes for customized 3D effects.
Key Features:
Technical Specifications | MP399 Foaming Paste
Key technical data and ecological compliance information for MP399 high foaming paste.
Product Specifications
Printing Guide | MP399 High Foaming Paste
Best practices for preparing, printing, and curing MP399 to achieve consistent 3D results.
Process Parameters
| Recommended Mesh | 100-120 mesh |
| Squeegee Hardness | 55-65 degree (Oil-based) |
| Humidity Warning | Extend curing if humidity > 80% |
| Curing Temperature | 150-160°C |
| Curing Time | 90 seconds |
| Heat Press Option | 155°C × 12 seconds |
Application Workflow
Mix MP399 with common paste (standard 50:50 ratio). Adjust ratio based on desired foaming height.
Screen print 3 passes (3 strokes each). Ensure an even deposit for uniform foaming.
In high humidity (>80%), increase drying/curing time to prevent stickiness and ensure fastness.
Pass through the oven at 150-160°C for 90 seconds to trigger the full 3D foaming reaction.
Performance Metrics
Typical results from standardized testing of MP399 on cotton substrates.
Test Conditions
Fabric
100% Cotton
Printing Method
3 passes, 3 strokes each
Curing Condition
155°C × 90s
Performance Metrics
Softness
Grade 3
5-grade scale (5=very soft, 1=hard)
Elasticity
Grade 2
5-grade scale (5=excellent, 1=poor)
Foaming Height
Superior
Visual assessment
Machine Wash Fastness
Pass
60°C wash cycles; wash & dry ×5
Anti-sticking
Pass
80°C under 5kg for 24h
Formulation Guidelines
Standard mixing recommendations for balancing foaming height and texture.
Standard Application Ratio
| Component |
|---|
| MP399 Foaming Paste |
| Common Printing Paste |
Storage & Safety Compliance
Guidelines for maintaining product shelf life and ensuring safe handling.
Storage Conditions
Temperature
5-35°C
Sealing
Keep container tightly sealed when not in use
Shelf Life
10 months from production
Important Warnings
- ⚠Store in a cool place; avoid exposure to direct sunlight
- ⚠Stir well before use to maintain homogeneous consistency
- ⚠Always conduct a trial test before mass production
- ⚠Keep out of reach of children
- ⚠Ensure proper ventilation in the printing area
