Water Based White Paste CMYK MP3399 | Machine Printing Paste | CLT
CLT MP3399 is a top-grade water-based white paste designed for CMYK machine printing. Features good fastness, high elasticity, easy to use, and is suitable for printing on oval and octopus printing machines.
Key Features:
Technical Specifications | MP3399 Water Based White Paste
Complete technical specifications for CLT MP3399 water-based white paste for CMYK printing.
Product Specifications
Printing Guide | MP3399 Water Based White Paste
Detailed printing instructions and technical parameters for optimal results with MP3399 paste.
Printing Conditions
| Humidity | 50-80% |
| Temperature | Room temperature |
| Squeegee Hardness | 75 (oil-based) |
| Mesh Count | 100-250 mesh |
| Curing Temperature | 140-150°C |
| Curing Time | 120 seconds |
Printing Process
Print MP3399 paste with proper squeegee pressure
Apply pigment mixture to achieve desired color
Cure at 140-150°C for 120 seconds for optimal fastness
Eco-Friendly Certifications & Test Results
MP3399 meets strict international environmental and safety standards.
Certifications
GB 18401
Chinese textile safety standard
OEKO-TEX 100
International textile safety standard
Adidas A-01
Adidas restricted substances list
Nike RSL
Nike restricted substances list
Harmful Substance Test Results
| Parameter | Value | Standard |
|---|---|---|
| Formaldehyde | <20 ppm | OEKO-TEX 100 |
| Soluble Heavy Metals | ND | EN71-3 |
| AZO Dyes | ND | OEKO-TEX 100 |
| APEO | ND | OEKO-TEX 100 |
| Phthalates | ND | OEKO-TEX 100 |
| Organo-tin Compounds | ND | OEKO-TEX 100 |
| Alkylphenols (AP) | ND | OEKO-TEX 100 |
Finished Product Performance
Test results for printed fabric using MP3399 water-based white paste.
Test Conditions
Fabric
100% Cotton
Printing Method
Machine printing
Curing Condition
135°C × 120s
Performance Metrics
Softness
3 Grade
5 Grade Scale (5=Super Soft, 1=Stiff)
Elasticity
1 Grade
5 Grade Scale (5=Very Good, 1=Worse)
Dry Rubbing Fastness
3-4
1-5 Scale
Wet Rubbing Fastness
4
1-5 Scale
Machine Wash Fastness
Pass
5 wash cycles at 60°C
Formulation & Auxiliaries
Recommended formulation and optional auxiliary agents for MP3399 paste.
Auxiliary Agents
Cross-linking Agent (PC-600)
Usage
1-2%
Purpose
Increase wash fastness and durability
Notes
Mix thoroughly and use within 72 hours. Test compatibility before mass production.
Wetting Agent (MDR)
Usage
As needed
Purpose
Prevent mesh clogging in low humidity conditions
Notes
Add when humidity is below 50%. Improves paste flow and application.
Storage & Shelf Life
Proper storage conditions ensure optimal performance and extended shelf life of MP3399 paste.
Storage Conditions
Temperature
5-35°C
Humidity
Keep in cool and ventilated place
Sealing
Well sealed containers
Shelf Life
6 months from manufacturing date
Important Warnings
- ⚠Keep away from direct sunlight and heat sources
- ⚠Avoid freezing - do not store below 5°C
- ⚠Store in sealed, airtight containers to prevent drying
- ⚠Keep away from incompatible materials
- ⚠Maintain proper ventilation in storage area
